STUMP GRINDER - BARRETO 37SGB


	Image for reference only Actual item may look different Click on image for larger view Click on above thumbnails for alternate view

Manufacturer: BARRETO

Model: E37SGB

4 Hour: $280.00

Daily: $350.00

3 Day: $1,050.00

Weekly: $1,050.00

Monthly: $2,625.00

Quantity: for a period of
4 hour(s) day(s) 3 day(s) week(s) month(s)

Additional Information

BARRETO E37SGB STUMP GRINDER - RENTAL COMES WITH TRAILER
For a helpful tutorial video visit https://www.youtube.com/watch?v=WI72BvWX8zU
*ALWAYS start grinding at the EDGE of stump and work your way in towards the middle of the stump. NEVER start grinding in the Middle of the stump, or you will damage machine!!!
SPECIFICATIONS:
ENGINE: Briggs & Stratton Vanguard V-Twin 37hp
Fuel: Gasoline
Fuel Tank Size: 5 Gal
DETAILS:
Height: 49.5
Length (head to side): 79
Length (head straight): 98
Width: 35.5
Weight: 1950 lb.
Hydraulic Reservoir: 14 gallons
Hydraulic Flow to Head: 13.3gpm
Track Width: 7.1
Total Ground Contact: 470 sq. in.
Ground Drive Forward: 290 ft/min
Ground Drive Reverse: 180 ft/min
WHEEL SPECIFICATIONS
Cutting Wheel: 19.2 diameter to tooth
Cutting Teeth: 0.750 thick, 16 green teeth
Cutting Depth: 12
Cutting Height: 32
Head Swing: 134 , 99.7 arc
FEATURES
Easy controls operate the track drive and cutter wheel
Time-tested track design absorbs impact and provides stability
Center-mounted cutter wheel provides 134 head swing
Gear pumps coupled to the engine drive the cutter wheel, tilt, and swing
Counterbalance valves on each track drive prevent motors from slipping
DESIGN
The 37SG stump grinder features a variant of the same time-tested track drive platform used by the RTK trencher series. The 37SG has a hydraulically-driven cutter wheel that is raised and lowered into the stump and then moved from side to side to cut down. The 37SG is powered by a 37hp Briggs & Stratton Vanguard V-Twin engine. The engine is coupled to two gear pumps: the larger gear pump drives the cutter wheel and the smaller pump works the tilt and swing cylinders. The tracks are driven by independent hydrostatic pumps mounted on the rear of the engine for easy access and simple linkage control. Counterbalance valves on each track drive prevent the track motors from slipping while the cutter wheel is engaged in the cutting process, even while operating on a slope.
CONTROLS
The cutter wheel operation and articulating arm are operated by controls mounted on the console. The cutter wheel is activated by a switch on the control stick and has a secondary safety switch to prevent accidental engagement. Back and forth movement across the stump, as well as depth of cut, are easily controlled by handles on the console, allowing for carefully controlled movement of the cutter wheel as it reduces the stump to chips.
ROI
All hydraulic drive to the cutter wheel eliminates costly belts. It also increases customer satisfaction by ensuring there is no loss of power because of a damaged belt or mechanical component. The track drive increases maneuverability around the job site, creating customer satisfaction by allowing them to get the job done with increased efficiency.
